What is the Towing Capacity of a Ford F-250?

Power and prestige go hand in hand when you drive a 2020 Ford F-250. This truck is part of the vigorous Super Duty® lineup, a distinction that puts this model squarely in the heavy-duty truck category. To explore 2020 Ford F-250 towing capacities, review the following guide. If you have any questions for a member of RiverBend Ford's team in Bainbridge, GA, please contact us by phone at (877) 340-0441.

2020 Ford F-250
Towing Capacity by Engine

6.2L 2-Valve Gas V8

The 6.2L V8 Super Duty® engine was created for your tough workday tasks and emits up to 385 HP and 430 lb.-ft. of torque, which combine for a maximum of 15,800 lbs. of fifth wheel towing capacity. These specs are achieved with a SOHC valvetrain with roller-rocker shafts which enables a layout that optimizes airflow.

New 7.3L Gas V8

The all-new 7.3L Gas V8 engine is a formidable addition to the Super Duty lineup. This engine outputs up to 430 HP and 475 lb.-ft. of torque, which leads to 19,500 lbs. in maximum towing capacity when properly equipped. Port injection with variable-valve timing elevates the intake and exhaust of this engine to increase performance, while oil jets cool the pistons when towing heavy loads.

6.7L V8 Power Stroke® Turbo Diesel

The 6.7L V8 Power Stroke® engine delivers an impressive maximum towing capacity of 22,800 lbs., achieved with up to 475 HP and 1,050 lb.-ft. of torque. To reduce noise and improve combustion, a new 36,000-psi fuel injection system with all-new injectors is incorporated in the 6.7L V8 Power Stroke engine. This turbo diesel powertrain also includes new steel pistons designed to deliver dynamic specs.

2020 Ford F-250 Engines 6.2L V8 7.3L V8 6.7L V8 Power Stroke Turbo Diesel
Horsepower 385 HP
430 HP
475 HP
Torque 430 lb.-ft. of torque @ 3,800 RPM
475 lb.-ft. of torque @ 4,000 RPM
1,050 lb.-ft. of torque @ 1,600 RPM
Max Towing Capacity 15,000 lbs.
15,000 lbs.
20,000 lbs.
Fifth wheel towing capacity 15,800 lbs.
19,500 lbs.
22,800 lbs. max.

2020 Ford F-250
Payload Capacity

The maximum 2020 Ford F-250 payload capacity is 4,260 lbs., more than enough to store extraneous tools and cargo inside your truck as well as yourself and your passengers.


2020 Ford F-250
Towing Assist Technology

Pro Trailer Backup Assist™

Using a physical knob on the instrument panel, control the direction you want your trailer to go while in reverse.

Trailer Sway Control

AdvanceTrac® with Roll Stability Control™ works together with trailer sway control to reduce the sway of your towed trailer if necessary.

Standard Hill Start Assist

If the engine isn't producing enough torque to go uphill, hill start assist will prevent the F-250 from rolling backwards by briefly applying the brakes.

Trailer Reverse Guidance

Using three cameras, trailer reverse guidance provides assistance with maneuvering trailers while backing up. This feature is designed to work with both conventional and fifth wheel/gooseneck towing.
